Density Meter
Applicable to: rubber, plastic, wire and cable, metal, glass, composite materials... and any non - absorbent, irregular solids, pastes, and granular materials.
Standards: ASTM D792, ASTM D297, GB/T1033, GB/T2951, GB/T3850, GB/T533, HG4 - 1468, JIS K6268, ISO 2781, ISO 1183...
SL-D300 0.001g/cm³
| SL-D500 0.0001g/cm³ (Standard with windproof cover)
|
Function description:
(1) Digital display for direct reading, no manual calculation required. It directly shows the density and volume.
(2) It can quickly measure similar products such as plastic particles, wire and cable granulates, films, floating bodies (such as EPE pearl cotton, etc.), rubber, seals, O - rings, ceramics, metals, pastes, etc.
(3) It has an actual water temperature compensation function and can adapt to changes in the test environment.
(4) The density of the medium liquid can be set. Water can be used as the medium, or other liquid media can also be used.
(5) The measurement platform is made of ABS injection - molded material, which is corrosion - resistant and drop - resistant, and comes with a lifetime free replacement service.
(6) It is equipped with an imported sensor. The repeatability error can reach ±0.001g/cm³, and it has automatic overload protection, being sturdy and durable.
(7) It uses imported silent mechanical buttons from Omron, Japan, with a lifetime warranty.
(8) It is equipped with an RS - 232C communication interface, which is convenient for connecting to a PC and a printer. The SL - P1 printer can be purchased to print measurement data.
Technical parameters:
Model | MZ-A300 | MZ-A150 |
Maximum weighing | 0.005-300g | 0.001-150g |
Density accuracy | 0.001 g/cm3 | 0.0001 g/cm3 |
Repeatability accuracy | ±0.001g/cm3 | ±0.0003g/cm3 |
Density range | 0.001~99.999g/cm3 | |
Measurement types | Non - absorbent solids, pastes: such as rubber, plastic, PS boards, wire and cable materials, pearl cotton, alloys, powder metallurgy finished products, dense ceramics, magnetic material finished products, sealants, asphalt adhesives, gemstones, rocks, etc., and PVC/PE/PP/ABS/PPS/PS and other granules | |
Measurement principle | Archimedes' principle of water displacement | |
Measurement time | Approximately 5 seconds | |
Measurement steps | 1. Place the sample on the measurement platform and press the save button to memorize; 2. Place it on the hanging basket in water and press the save button to directly display the density and volume | |
Result display | Density, volume | |
Parameter setting | Water temperature setting, medium liquid density setting | |
Calibration method | One - key automatic calibration | |
Output method | RS - 232C standard communication interface, convenient for test data output and printing | |
Temperature and humidity range | Allowed ambient temperature: 0~45℃; Allowed relative humidity: within 80% | |
Power supply | AC~220V / 50HZ | |
Operation panel | Imported Omron Chinese - English mechanical buttons from Japan | |
Standard accessories | ① One main unit, ② One water tank, ③ One measurement platform, ④ One pair of tweezers, ⑤ One dropper, ⑥ One weight, ⑦ One power transformer, ⑧ One set of accessories for measuring particles, ⑨ One set of accessories for measuring floating bodies | |
Other parameters | Outer package size: 395195330mm; Body size: 210195185mm (HS code for export customs: 90160090) | |
